| Parameter |
Unit |
Value |
| Brightness |
nits |
4500 |
| Viewing angle - Horizontal |
deg. |
120(﹢60/﹣60) |
| Viewing angle - Vertical |
deg. |
60(﹢30/﹣30) |
| Cabinet Weight |
kg |
58 |
| Cabinet Width |
mm |
1280 |
| Cabinet height |
mm |
960 |
| Cabinet depth |
mm |
185 |
| Cabinet area |
sq. m. |
1.23 |
| Cabinet material |
|
Steel |
| Aspect ratio |
|
4 : 3 |
| Ingress Protection (Front/Rear) |
IP |
IP65/IP43 |
|
Operating temperature range
|
deg. C |
-20 to 50 |
| Operating Humidity range |
HR |
10％ to 90％ |
| Pixel type and configuration |
R/G/B |
1,1 |
| Pixel pitch |
mm |
10 |
| Pixel matrix per cabinet |
|
128 x 96 |
| Pixels per cabinet |
|
12288 |
| Lines per meter |
|
100 |
| Pixels per sq. meter |
|
10000 |
| LEDs per sq. meter |
|
10000 |
| Recommended minimum viewing distance |
m |
5 |
| Colours |
|
65536 |
| Gray scale |
Levels |
256 levels per colour |
| Brightness control |
Levels |
8 |
| Digital processing |
bit |
8 |
| Display refresh rate |
Hertz |
≥300 |
| Scan mode |
|
1/4 duty scan drive |
| Input voltage |
VAC |
110 / 240 |
| Input voltage |
VAC |
50 or 60 |
| Input power (max/avg) |
Watts per sq.m |
300/80 |
